Product Details:
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-08-03
Payment & Shipping Terms:
Minimum Order Quantity: 1*20GP
Packaging Details: Carton box and pallet
Delivery Time: 7-25 days after advance deposit
Payment Terms: T/T;L/C
Contact Now
Detailed Product Description
Product Name: Insulation Refractory Board Shape:: Brick
Feature:: Heat Insulation Usage:: Glass Furnace,Coke Oven,Blast Furnace
Material:: Calcium Silicate Temperature Range: 650 º C - 1100º C
High Light:

calcium silicate insulation board

,

calcium silicate board partition



Interior Wall Calcium Silicate Board Heat Insulation Fireproof ISO9001

Description:

Calcium silicate board is an asbestos-free thermal insulation product that can withstand continuous operating temperature from650C up to1100C. It is light weight, low thermal conductivity, high strength, easy to install, reliable and durable. There are 3 grades available namely 650 &1000 & 1100 which are commonly used as furnace backup insulation in steel, petrochemical, ceramic, cement & glass industry or fire protection in building construction. It not only provides energy saving, also increases production efficiency and gives personnel protection in industrial safety aspect. And in the housing construction Calcium Silicate Board is also used as the ceiling, fireproof and heat insulation materials of wall and sound absorption materials of decoration.

Applications:
Reheating furnace -Annealing furnace-Transfer ladle -Rotary kiln-Glass tank Dip tubes and spouts Nozzles -Shuttle kiln -Tunnel kiln -Aluminum melting and holding furnace- Distribution boxes, Flow gates Hot pipe supports-Other high temperature ovens or heat processing equipments

Recommendable applications:

Commercial building: Commerce mansions, entertainment sites, shopping malls and hotels
Industrial building: Factories and warehouses
Residential building: New residential housing, renovation and decoration
Public place: Hospitals, theater and bus stations
Key Specifications/Special Features:


Specifications:
650 & 1000 C     600-1000 mmX 300-500mm X 25-100mm    Speicial deimension will be as per customer request

High Strength Calcium Silicate Boards have the characters of big size, high strength and proof-fire etc. The boards can be widely used as energy-saving materials for almost all types of industrial furnaces, steel structure fire proof, partition, air duct, cable tray and stile & fire door, etc.

High Strength Calcium Silicate Boards

Items

Unit

Index

Bulk Density

Kg/m3

800-1000

Flexural Strength

MPa

6

Compressive Strength

MPa

12

Screw Holding Strength
(50×φ5mm screw,deep 25mm)

N

positive 1800
side 1500

(200℃) Thermal Cond.

W/m.k

0.13

(1000℃ 3h)Thermal Cond

%

1.5



Block Sizes and Dimensional Tolerances

Length mm(±5mm)

Width mm(±4mm)

Thickness mm(+2,-1.5mm)

2300-2500

1200

13-43

Please contact us if customers require other sizes and specifications.
