Insulating Ceramic Fiber Refractory Module For Refining Petrochemical Steel Industry

Good quality Fire Brick Refractory for sales
Good quality Fire Brick Refractory for sales
Very good service and products all the time. Thank you.

—— Kelvin ( Chile )

we appreciate for your good products and service all the time. Thanks

—— Rafael(Peru)

This is the first time for our cooperation. They are indeed what we want. We look forward to working with you again in the near future.

—— Thomas(Thailand)

Our client satisfied with the SK-32 fire bricks . But It would be better if the delivery time be shorter in our next order.

—— John Kim ( Korea)

Jacky,I want to inform We are very happy about the quality of the packing and personalization and we thank you for all the help and support.

—— Catalin Olaru(Romania)

The items are better than we expected. Good. Thank you!

—— Abraham(Philippines)

The samples arrived. We are pleased with the quality. Waiting for our cooperation soon.

—— Adam( Spain)

I hope you are fine and business is well. We recieved the goods from you and we are pleased about the quality of them.

—— Catalin Olaru(Romania)

I'm Online Chat Now

Insulating Ceramic Fiber Refractory Module For Refining Petrochemical Steel Industry

China Insulating Ceramic Fiber Refractory Module For Refining Petrochemical Steel Industry supplier

Large Image :  Insulating Ceramic Fiber Refractory Module For Refining Petrochemical Steel Industry

Product Details:

Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-02-03

Payment & Shipping Terms:

Minimum Order Quantity: 3 ton
Packaging Details: Carton box
Delivery Time: 10~15 days
Payment Terms: T/T;L/C
Supply Ability: 500 ton/month
Detailed Product Description
Product Name: Insulation Refractory Type: Module
Feature:: High Purity,Corrosion Resistance,light Weight Usage: Refining Petrochemical Steel Industry
Material:: Ceramic Fiber Temperature Range: 1000℃ To 1350 ℃



Insulating Ceramic Fiber Refractory Module For Refining Petrochemical Steel Industry



Description:

Laurel modules have the highest insulating value achievable in a ceamic fiber. Each module is a continuous folded blanket under compression.The individual sheetsis allowed.

Module linings prevent heat loss,increasing the furnace productivity and reducing maintenance costs.



Features

  1. Fast and easy installation
  2. Lower heat storage and fuel costs
  3. This design creates a very ligh lining,less steel required
  4. Several anchor systems
  5. Fast and easy installation
  6. Lower heat storage and fuel costs
  7. This design creates a very ligh lining,less steel required
  8. Several anchor systems



Applications:

Ceramic industry

  1. Low mass kiln cars
  2. Continuous and batch kilns
  3. Door linings
  4. Glazing,porcelain furnace linings

Power generation

  1. Duct lining
  2. Heat recovery steam system
  3. Boiler insulation
  4. Stack linings

Refining and petrochemical

  1. Ethylene furnace roof and walls
  2. Pyrolysis furnace lining
  3. Reformer furnace roof and walls
  4. Boiler linings

Steel industry

  1. Ladle pre-heaters and covers
  2. Heat treat furnace
  3. Soaking pit covers and seals
  4. Heaters and reformer lining

Others

  1. Incineration equipment
  2. Burner blocks
  3. Induction furnace covers
  4. Glass tempering furnace.



Specifications:

Technical data

Item

Common

Standard

H Pure

H Alumina

Zirconium

AL2O3(%)

44

46

47-50

52-55

39-40

Fe2O3(%)

1.2

1.0

0.2

0.2

0.2

ZrO2(%)

15-19

Classification Temperature (℃)

1100

1260

1260

1360

1430

Working Temperature (℃)

1000

1050

1100

1200

1350

Density (kg/m3)

220±15

220±15

220±15

220±15

220±15

Permanent linear shrinkage(%)(after24 hours,density 128kg/m3)

 -4
(1000°C)

-3
(1000°C)

-3
(1100°C)

-3
(1250°C)

-3
(1350°C)



Competitive Advantage:

1.Best price, make the products competitive in your market

2.Abundant Experience.

3.Strict Quality Control. Meet clients'quality requirement.

4.Large stocks. Guarantee prompt delivery.

5.Professional Packing. Avoid damage and secure the goods in transportation
