Coke ovens Alumina Fire Clay Brick / Glass Furnace , Low thermal conductivity

Basic Information
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-01
Minimum Order Quantity: 20 ton
Packaging Details: packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages
Delivery Time: 20~30 days
Payment Terms: T/T;L/C
Supply Ability: 20,000 ton/Year
Product Name: Silica Insulation Refractory Shape:: Brick
Feature:: Low Thermal Conductivity,high Strength Usage: Linings, Furnaces And Kilns Etc
Temperature Range: Above 1670°C Material:: 30-55% Alumina
High Light:

clay fire bricks

,

fired clay brick



Coke ovens Alumina Fire Clay Brick / Glass Furnace , Low thermal conductivity







From company establish, we are insisting on the principle of "quality first,best service ,competive price"



Description:

Laurel produces a comprehensive range of Fire clay brick consisting of 30-55% Alumina all of which exhibit excellent strength. For more arduous environments we offer a hand fired “super duty” Fire clay brick with a very high mechanical strength.





Features:

1. Low thermal conductivity, good thermal insulation performance.

2. Long service life, easy operation, could be shaped freely

3. Product specification: standard form, normal standard, shaped and special shaped bricks.

4. Can be used in various kilns because of its cheapness and general tray package. Among all of the refractory materials, it is the most widely used.





Applications:

1. Carbon bake furnaces in the aluminum industry

2. Preheat zones and cyclones of rotary cement kilns

3. Insulation for glass tanks

4. Fireplace and pizza ovens

5. Coke ovens

6. Blast furnaces

7. Reheating furnaces

8. Suspended roofs

9. Lime kilns

10. Chimney



Specifications:

Technical data



Item

SK-30

SK-32

SK-34

SK-36

SK-38

AL2O3 %   (min)

30-35%

35-38%

38-42%

50-55%

60-65%

Fe2O3%   (max)

3

3

2.8

2.5

2.3

Refractoriness

≥1670°C

≥1690°C

≥1710°C

≥1750°C

1770°C

Refractoriness under load, 0.2MPa, (°C)

1270

1350

1350

≥1430

≥1450

Apparent porosity (%)

20-24

20-24

19-23

18-22

18-22

Bulk density (g/cm³)

2.00-2.05

2.05-2.1

2.1-2.15

2.15-2.25

2.25-2.35

Cold crushing strength (MPa)

25

≥30

35

≥45

≥50

Thermal expansion at 1000°C (%)

≤0.6

≤0.55

≤0.55

≤0.4

≤0.4







Competitive Advantage:

  1. Competitive Price. Make the products competitive in your market.
  2. Abundant Experience. Prevent cracks and twist in bricks.
  3. Different Moulds. Save mould fees for you.
  4. Strict Quality Control. Meet clients’ quality requirement.
  5. Large stocks. Guarantee prompt delivery.
