Energy saving Refractory Fire Clay Brick For Tunnel Kiln , Furnaces

Basic Information
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-05-01
Minimum Order Quantity: 20 GP
Packaging Details: packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages
Delivery Time: 15~30 days
Payment Terms: T/T;L/C
Supply Ability: 10000 ton
Product Name: Insulating Brick Usage: Furnaces And Kilns Etc
Material:: Mullite Brick Bulk Density: 0.8-1g/cm3
Feature:: Energy Saving,Corrosion Resistance Temperature Range: 1260℃ To 1760℃
High Light:

ceramic fire brick

,

insulated fire brick



Energy saving Refractory Fire Clay Brick For Tunnel Kiln , furnaces





The most competitive price , good quality , safty packing , prompt delivery time , and excellent after-sales services.



Specifications:

JM serises

Item

JM23

JM26

JM28

JM30

AL2O3(%)

38-44

50-58

65-70

70-73

Fe2O3(%)

1.0

0.9

0.8

0.7

Classification Temperature (℃)

1350

1430

1540

1600

Bulk Density (g/cm3)

0.8-1

0.8-1

0.8-1

0.8-1

Reheating Linear Change (%)

  CT-30 ℃X 8H

1250℃

-0.5

1400℃

-0.5

1500℃

-0.5

1550℃

-0.5

Cold Crushing Strength (Mpa)

3.0-4.5

3.0-4.5

3.0-4.5

3.0-4.5

Modulus of Rupture (Mpa)

1.5

1.7

1.8

2.0

Thermal conductivity400℃(W/m.k)

0.25

0.27

0.32

0.41

Thermal Expansion1000℃(%)

0.5

0.7

0.8

0.9





B C serises

Item

B-1

C-1

C-2

AL2O3(%)

25-30

35-40

45-50

Fe2O3(%)

2

1

1

Classification Temperature (℃)

1000

1300

1400

Bulk Density (g/cm3)

0.8-1

0.8-1

0.8-1

Cold Crushing Strength (Mpa)

2-2.5

2.5-3.5

3.0-4.5

Thermal conductivity400℃(W/m.k)

0.17

0.23

0.25



Description:



Insulating bricks are manufactured utilising exceptionally high purity clays and other ceramic materials.The carefully graded organics which are used during the manufacturing process burn out during firing to give a uniform pore structure.



Features



1. Strong compressive strength

2. Low heat storage

3. High purity

4. Tight dimensional tolerance

5. Energy saving

6. Low impurities



Applications:

1. Primary hot face linings

2. Back-up insulation for furnaces and kilns

3. Flue insulation

4. Sulphur recovery equipment





Competitive Advantage:

1. Best price, make the products competitive in your market

2. Abundant Experience.

3. Strict Quality Control. Meet clients'quality requirement.

4. Large stocks. Guarantee prompt delivery.

5. Professional Packing. Avoid damage and secure the goods in transportation
