High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature

Basic Information
Place of Origin: CHINA
Brand Name: Laurel
Certification: ISO9001, CE
Model Number: LAUREL-01
Minimum Order Quantity: 1 tons
Price: USD 120- 300 / tons
Packaging Details: packed on wooden pallets,with water-proof cover,and tightened with plastic/steel bandages
Delivery Time: 10-25 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 2000 tons / months
Shape: Brick, Block, 230*114*65mm Or Customerized, Standard Or Customized By Your Drawings Al2o3 Content (%): 35-80%
Refractoriness (degree): Common (1580°< Refractoriness< 1770°), 1770°< Refractoriness< 2000° Color: Brown
Density: 2.15-2.7 G/cm3 Feature 1: High Strength
Feature 2: High Temperature Feature 3: Fire Proof
Feature 4: Thermal Shock Resistance Size: Customizable, 230x114x65mm, 230mm*114mm*76mm
Application: Refractory, Industrial Furnaces, Hot Blast Stove, Refractory Brick For Pizza Ovens, Etc
High Light:

80% Alumina Refractory Fire Clay Brick

,

Steel Industry Refractory Fire Clay Brick

 High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature

High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 0



Laurel produces a comprehensive range of Fire clay brick consisting of 30-55% Alumina all of which exhibit excellent strength. For more arduous environments we offer a hand fired "super duty" Fire clay brick with a very high mechanical strength.

Typically our firebrick range is based upon flint clay giving it both a low iron and low alkali characteristic. Resistance to thermal shock, abrasion, chemical attack and reducing atmospheres are just some of the key criteria determining choice of product within each application. a wide range of sizes are held in stock.

High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 1

High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 2



High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 3

Item SK-30 SK-32 SK-34 SK-36 SK-38
AL2O3 % (min) 30-35% 35-38% 38-42% 50-55% 60-65%
Fe2O3% (max) 3 3 2.8 2.5 2.3
Refractoriness ≥1670°C ≥1690°C ≥1710°C ≥1750°C ≥1770°C
Refractoriness under load, 0.2MPa, (°C) ≥1270 ≥1350 ≥1350 ≥1430 ≥1450
Apparent porosity (%) 20-24 20-24 19-23 18-22 18-22
Bulk density (g/cm³) 2.00-2.05 2.05-2.1 2.1-2.15 2.15-2.25 2.25-2.35
Cold crushing strength (MPa) ≥25 ≥30 ≥35 ≥45 ≥50
Thermal expansion at 1000°C (%) ≤0.6 ≤0.55 ≤0.55 ≤0.4 ≤0.4





High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 4



High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 5

1.High mechanical strength
2.Good thermal shock resistance
3.Good resistance to abrasion and corrosion
4.Good volume stability at high temperature





High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 6



Advantage :



1.Competitive Price. Make the products competitive in your market.

2.Abundant Experience. Prevent cracks and twist in bricks.

3.Different Moulds. Save mould fees for you.

4.Lower ferric Oxide,porosity,higher refractoriness,density,higher CCS and exact tolerance.

5.Strict Quality Control. Meet clients' quality requirement.

6.Safty packing,prompt delivery time,and excellent after-sales services.

7.Large stocks. Guarantee prompt delivery.

8.Professional Packing. Avoid damage and secure the goods in transportation.



High Alumina Refractory Fire Clay Brick for Steel Industry High Temperature 7





Application  :



Iron & steel making:Blast furnace,hot blast stove,hot metal ladle,tundish,soaking pit,heat treatment furnace,refining furnace,reheating furnace,metal mixter furnace,cupola furnace.
Non-ferrous Metal:Smelting furnace,reverberatory furnace.
Building materials:Cement kiln,glass kiln,ceramic kiln,lime kins,kiln car,tunnel kiln,rotary kiln.
Energy &Incineration:Coke oven,boiler,power generation boiler,CFB boiler,electric furnace,carbon roasting furnace,waste incinerators.
Others:Petrochemical industry furnace,pizza oven.







HIGH LIGHT :

high temperature fire brick, alumina silica fire brick,fire proof bricks, clay fire bricks, insulating refractory brick
