Walling Plate Calcium Silicate Wall Board Light Weight Decorative Material

Basic Information
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: calcium silicate insulation board
Minimum Order Quantity: 1 pcs
Price: USD 3-20/ pcs
Packaging Details: Carton box and pallet
Delivery Time: 7-25 days after advance deposit
Payment Terms: T/T;L/C
Supply Ability: 500TON/MON
Product Name: Insulation Refractory Board Shape:: Panel
Feature:: Heat Insulation Usage:: Glass Furnace,Coke Oven,Blast Furnace
Material:: Calcium Silicate Temperature Range: 650 º C - 1100º C
Color: White Thickness: 3-30mm
Product Name: Calcium Silicate Board Feature: Fireproof,Thermal-insulation
Application: Partition/ceiling/flooring/roofing Packing: Carton With Pallet
Advantage: Fireproof Density: 213-230kg/m3
High Light:

Lightweight Calcium Silicate Wall Board

,

Partition Calcium Silicate Wall Board

,

Walling Calcium Silicate Board

Light weight walling plate decorative material calcium silicate wall board



Laurel Group is established in 2003 and located in the North of China, Shandong province,specialized in the
producing and selling of all types of refractory and insulation materials, including fire clay bricks, high alumina
bricks, insulating bricks, ceramic fiber products, calcium silicate products and unshaped materials.







Brief description

Calcium silicate board is an asbestos-free thermal insulation product that can withstand continuous operating temperature from 650C up to 1100C. It is light weight, low thermal conductivity, high strength, easy to install, reliable and durable. There are 3 grades available namely 650 &1000 & 1100 which are commonly used as furnace backup insulation in steel, petrochemical, ceramic, cement & glass industry or fire protection in building construction. It not only provides energy saving, also increases production efficiency and gives personnel protection in industrial safety aspect. And in the housing construction Calcium Silicate Board is also used as the ceiling, fireproof and heat insulation materials of wall and sound absorption materials of decoration.


Walling Plate Calcium Silicate Wall Board Light Weight Decorative Material 2


Specifications:
650 & 1000 C     600-1000 mmX 300-500mm X 25-100mm    Speicial deimension will be as per customer request

High Strength Calcium Silicate Boards have the characters of big size, high strength and proof-fire etc. The boards can be widely used as energy-saving materials for almost all types of industrial furnaces, steel structure fire proof, partition, air duct, cable tray and stile & fire door, etc.










High Strength Calcium Silicate Boards

Items

Unit

Index

Bulk Density

Kg/m3

800-1000

Flexural Strength

MPa

6

Compressive Strength

MPa

12

Screw Holding Strength
(50×φ5mm screw,deep 25mm)

N

positive 1800
side 1500

(200℃) Thermal Cond.

W/m.k

0.13

(1000℃ 3h)Thermal Cond

%

1.5


 Block Sizes and Dimensional Tolerances

Length mm(±5mm)

Width mm(±4mm)

Thickness mm(+2,-1.5mm)

2300-2500

1200

13-43



Walling Plate Calcium Silicate Wall Board Light Weight Decorative Material 4





1. Light bulk weight, Low thermal conductivity

2. High bending and compressive strength

3. Good durability

4. Strong practicability in construction

5. Non-toxic, non hazardous substances



Applications:
Reheating furnace -Annealing furnace-Transfer ladle -Rotary kiln-Glass tank Dip tubes and spouts Nozzles -Shuttle kiln -Tunnel kiln -Aluminum melting and holding furnace- Distribution boxes, Flow gates Hot pipe supports-Other high temperature ovens or heat processing equipments

Recommendable applications:
Commercial building: Commerce mansions, entertainment sites, shopping malls and hotels
Industrial building: Factories and warehouses
Residential building: New residential housing, renovation and decoration
Public place: Hospitals, theater and bus stations
