High Temperature Kiln Linings Fireproof Fire Brick Refractory Alumina Corundum Bricks

Basic Information
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-08-01
Minimum Order Quantity: 20 ton
Packaging Details: packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages
Delivery Time: 20~30 days
Payment Terms: T/T;L/C
Supply Ability: 5000 ton/Year
Product Name: Insulation Refractory Shape:: Bricks
Feature:: High Density Strength,thermal Shocking Resistance Usage: Linings, Furnaces And Kilns Etc
Material:: Alumina Brick Temperature Range: High Temperature
Highlight:

high temperature refractory

,

refractory brick panels



Kiln Linings Fire Brick Refractory High Temperature , Alumina Corundum Bricks



Description:

The sintered corundum products were produced by sintering of high purity fused corundum, synthetic mullite and chromium oxide. They have high bulk density, high compressive strength, good thermal shocking resistance, and good corrosion resistances to acids and alkali. They are not influenced by H2, CO gases at use.



Features:

1.high bulk density

2.high compressive strength

3.good thermal shocking resistance



Applications:

Widely used as linings in decomposing furnaces for petroleum and chemical industry,

as well as chemical fertilizer industry. They also used as high temperature kiln linings

and furniture’s in metallurgical industry.



Specifications:

Technical data

Brand

AL-98

AL-95

AL-90

AL-80

AL-85

Chemical Analysis

AL2O3

(%)

≥98.5

≥95

≥90

≥80

≥85

Cr2O3

(%)

---

---

---

---

≥8

SiO2

(%)

≤0.3

≤3.0

≤9.0

≤18

≤0.2

Fe2O3

(%)

≤0.2

≤0.2

≤0.5

≤0.5

≤0.2

R2O

(%)

≤0.3

≤0.6

≤0.6

≤0.4

≤0.5

Bulk Density

(g/cm3)

≥3.0

≥2.9

≥2.9

≥2.7

≥3.1

C.C.S

(Mpa)

≥75

≥100

≥100

≥60

≥80

Refractoriness

(℃)

≥1790

≥1790

≥1790

≥1790

≥1790

Refractoriness
under load of 0.2MPa

(℃)

≥1700

≥1650

≥1650

≥1700

≥1700

Reheat Linear Change

(%)

1600℃×3h
≤0.2

1600×3h
≤0.2

1600×3h
≤0.2

1600×3h
≤0.3

1600×3h
≤0.2

Thermal Shock Resistance
1100℃water cooling

(times)

≥6

≥10

≥10

≥20

≥15



Competitive Advantage:

  1. Competitive Price. Make the products competitive in your market.
  2. Abundant Experience. Prevent cracks and twist in bricks.
  3. Different Moulds. Save mould fees for you.
  4. Strict Quality Control. Meet clients’ quality requirement.
  5. Large stocks. Guarantee prompt delivery.
  6. Professional Packing. Avoid damage and secure the goods in transportation
