Application: | Chimney Lining,Pharmaceutical Industry | Product Name: | Insulation Refractory |
---|---|---|---|
Feature:: | Heat Insulating | Name: | Cellular Glass Pipe Insulation |
Material:: | Foam | Working Temp: | -200~450°C |
Highlight: | heat insulation material,insulation foam glass |
Pipe Foam Cellular Form Glass for Chimney lining and pharmaceutical Industry
Description:
Foam glass is a new kind of inorganic heat insulating material with a structure of equally closed cells. It is mainly made of glass added with adequate foaming agents after heating and baking in high-temperature tunnel furnace, then annealing and cooling.
Specification
1.Blocks:620(max.)*480(max.)*(20~150)mm
2.Pipe Sections: Sealing caps of equipment and products of special form could be processed according to constmers' requirements.
Item |
|
numeral(standard/reality) |
item |
|
numeral(standard/reality) |
Density |
Kg/m3 |
160±10 |
compression strength |
Mpa |
≥0.8 |
Heat Conductivity |
(25°C)W/m.k |
≤0.062/0.056 |
bending strength |
Mpa |
≥0.8 |
Working temp |
°C |
-200~450 |
moisture rate |
% |
0.00 |
water absorption |
% |
≤0.5/0.2 |
coefficient of linear expansion |
cm/cmc |
9×10-6/8.5×10-6 |
Applications:
The cellular glass is widely applied to the petroleum, chemical, the underground project, the shipbuilding, the national defense war industry's heat insulaton heat preservation guarantees coldly.
1.Low-temperature piping, equipment and tanks( for storage).
2.Low-temperature system for hydrocarbon processing;
3.Refrigerated warehouse and chilled construction;
4.Low-temperature insulated system for pharmaceutical Industry;
5.steel storage tanks and piping for liquid oxygen and nitrogen;
6.Underground steam and cooling water piping;
7.Chimney lining;
8.Offshore oil platform;
9.Production system for hydrocarbon compounds;
10.Insulation for exterior and interior walls;
11.Waterproofing and insulation for roofs;
12.Steel plate roofing;
13. Insulation for thermal bridges;
14.Condensate piping for centralized air conditioning;
15.Site trench for industrial factories;
16.Base for hanging gardens.
Competitive Advantage:
1.Best price, make the products competitive in your market
2.Abundant Experience.
3.Strict Quality Control. Meet clients'quality requirement.
4.Large stocks. Guarantee prompt delivery.
5.Professional Packing. Avoid damage and secure the goods in transportation
