Specification: | Blocks:620(max.)*480(max.)*(20~150)mm | Density: | 160 Kg/m3 , 150 Kg/m3 |
---|---|---|---|
Working Temp: | -200~450 ℃ | Applications: | Chimney Lining Cellular Glass |
Product Name: | Foam Glass Insulation | Feature:: | Heat Insulating,Water Absorption |
Highlight: | heat insulation material,foam glass block |
Chimney Lining Cellular Glass Insulation Water Absorption Heat Insulating
Description:
Foam glass is a new kind of inorganic heat insulating material with a structure of equally closed cells. It is mainly made of glass added with adequate foaming agents after heating and baking in high-temperature tunnel furnace, then annealing and cooling.
Specification
1.Blocks:620(max.)*480(max.)*(20~150)mm
2.Pipe Sections: Sealing caps of equipment and products of special form could be processed according to constmers' requirements.
Item |
|
numeral(standard/reality) |
item |
|
numeral(standard/reality) |
Density |
Kg/m3 |
160±10 |
compression strength |
Mpa |
≥0.8 |
Heat Conductivity |
(25°C)W/m.k |
≤0.062/0.056 |
bending strength |
Mpa |
≥0.8 |
Working temp |
°C |
-200~450 |
moisture rate |
% |
0.00 |
water absorption |
% |
≤0.5/0.2 |
coefficient of linear expansion |
cm/cmc |
9×10-6/8.5×10-6 |
Applications:
The cellular glass is widely applied to the petroleum, chemical, the underground project, the shipbuilding, the national defense war industry's heat insulaton heat preservation guarantees coldly.
1.Low-temperature piping, equipment and tanks( for storage).
2.Low-temperature system for hydrocarbon processing;
3.Refrigerated warehouse and chilled construction;
4.Low-temperature insulated system for pharmaceutical Industry;
5.steel storage tanks and piping for liquid oxygen and nitrogen;
6.Underground steam and cooling water piping;
7.Chimney lining;
8.Offshore oil platform;
9.Production system for hydrocarbon compounds;
10.Insulation for exterior and interior walls;
11.Waterproofing and insulation for roofs;
12.Steel plate roofing;
13. Insulation for thermal bridges;
14.Condensate piping for centralized air conditioning;
15.Site trench for industrial factories;
16.Base for hanging gardens.
