high quality low thermal conductivity Light Weight Insulating Fire Brick Refractory Clay Fire Bricks

Basic Information
Place of Origin: Zibo, China
Brand Name: Laurel
Certification: ISO9001
Model Number: Laurel-05-02
Minimum Order Quantity: 20 GP
Packaging Details: packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages
Delivery Time: 15~30 days
Payment Terms: T/T;L/C
Supply Ability: 500 ton
Materials: Mullite Work Temperature: High Temperature
Keyword: Pizza Oven Fire Bricks Performance: Keeping Heat
Size: 230x114x64mm Sic: 1.2-1.4%
Highlight:

ceramic fire brick

,

insulated fire brick

Light Weight Insulating Fire Brick , Refractory Clay Fire Bricks



The most competitive price,good quality,safty packing,prompt delivery time,and excellent after-sales services.
Lighter weight,Low thermal conductivity,low impurities,high insulating properties,high CCS and exact tolerance.





Description:

It is a kind of the light weight refractory products which contains the alumina content range from 30% to 46% .

Ingredients and water mixed together made the plastic pug or slurry, then Extruded-Form or moulding by casting, dry, and firing in the 1250-1350°C oxidizing atmosphere.





Applications:

Mainly used as thermal insulating layer without the liquid melt touched or gas pickling in the constructing the various industry furnaces.

The working temperature is 1200-1400°C





Specifications:



Sunrise Brand

LA-0.5

LA-0. 6

LA-0. 8

LA-1.0

LA-1.3

USA Brand

ISO125-0.5

ISO125-0.6

ISO135-0.8

ISO135-1.0

ISO140-1.2

Max Service Temperature (°C)

1150

1200

1280

1300

1350

Bulk Density (g/cm3)

0.55

0.6

0.8

1.0

1.3

Apparent Porosity %

80

70

60

55

50

Cold Crushing Strength

 (Mpa) ≥

1.5

2.0

2.5

3.0

4.0

Reheating Linear Change (%)   °CX 12H ≤

1250°C

-0.5

1300°C

-0.5

1350°C

-0.5

1350°C

-0.9

1350°C

-0.9

Thermal conductivity(W/m.k)

400°C

0.14

0.25

0.35

0.41



600°C

0.16

0.29

0.45

0.43







Competitive Advantage:

1.Best price, make the products competitive in your market

2.Abundant Experience.

3.Strict Quality Control. Meet clients'quality requirement.

4.Large stocks. Guarantee prompt delivery.

5.Professional Packing. Avoid damage and secure the goods in transportation



high quality low thermal conductivity Light Weight Insulating Fire Brick Refractory Clay Fire Bricks 0high quality low thermal conductivity Light Weight Insulating Fire Brick Refractory Clay Fire Bricks 1high quality low thermal conductivity Light Weight Insulating Fire Brick Refractory Clay Fire Bricks 2
