| Place of Origin: | Zibo, China |
|---|---|
| Brand Name: | Laurel |
| Certification: | ISO9001 |
| Model Number: | Laurel-05-01 |
| Minimum Order Quantity: | 20 GP |
| Packaging Details: | packed on wooden pallets, with water-proof cover, and tightened with plastic/steel bandages |
| Delivery Time: | 15~30 days |
| Payment Terms: | T/T;L/C |
| Supply Ability: | 10000 ton |
| Packing: | Wooden Pallets Or Cartons | Shape: | Rectangular |
|---|---|---|---|
| Alumina Content: | 35-45% | Grade: | JM23.JM26.JM28.JM30 |
| Thermal Conductivity: | 0.2-0.3 W/mK | Use Zone: | Transition Zone In Rotary Kiln |
| Thickness: | 3-30 Mm | Use: | Hot Blast Stove |
| Bending Strength: | 2 | Max Service Temperature: | 850-1150°C |
| Temperature Range: | High Temperature | Performance: | Keeping Heat |
| Highlight: | lightweight fire brick,ceramic fire brick |
||
Energy Saving Vermiculite High ceramic Fire Brick For Wood Stove Bbq Oven
Lightweight mullite brick, corundum mullite brick, and fused mullite bricks are premium high-temperature refractory materials designed for industrial furnaces, kilns, and high-temperature equipment. Known for excellent thermal stability, mechanical strength, and chemical resistance, these bricks ensure long-lasting performance in demanding environments.
These lightweight mullite bricks, corundum mullite bricks, and fused mullite bricks provide reliable high-temperature performance, exceptional durability, and chemical stability. They are ideal for industrial applications requiring premium refractory solutions.
These mullite bricks provide exceptional durability and high-temperature resistance. With low thermal expansion and high corrosion resistance, they are ideal for steel, glass, and ceramic industries. Available in standard and custom dimensions, these bricks meet diverse industrial requirements.
Description:
Laurel supply several grades of mullite insulating brick for use in applications frm 1260℃ to 1760℃.Each grade of brick is formulated to meet specific thermal and physical requirements.After firing each brick is machined to close dimensional tolerances.
Insulating bricks are manufactured utilising exceptionally high purity clays and other ceramic materials.The carefully graded organics which are used during the manufacturing process burn out during firing to give a uniform pore structure.
Features
1.High insulating properties
2.Strong compressive strength
3.Low heat storage
4.High purity
5.Tight dimensional tolerance
6.Energy saving
7.Low impurities
Applications:
1.Primary hot face linings
2.Back-up insulation for furnaces and kilns
3.Flue insulation
4.Sulphur recovery equipment
5.Hot blast stoves
Specifications:
JM serises
|
Item |
JM23 |
JM26 |
JM28 |
JM30 |
|
AL2O3(%) |
38-44 |
50-58 |
65-70 |
70-73 |
|
Fe2O3(%) |
1.0 |
0.9 |
0.8 |
0.7 |
|
Classification Temperature (℃) |
1350 |
1430 |
1540 |
1600 |
|
Bulk Density (g/cm3) |
0.8-1 |
0.8-1 |
0.8-1 |
0.8-1 |
|
Reheating Linear Change (%) CT-30 ℃X 8H |
1250℃ -0.5 |
1400℃ -0.5 |
1500℃ -0.5 |
1550℃ -0.5 |
|
Cold Crushing Strength (Mpa) |
3.0-4.5 |
3.0-4.5 |
3.0-4.5 |
3.0-4.5 |
|
Modulus of Rupture (Mpa) |
1.5 |
1.7 |
1.8 |
2.0 |
|
Thermal conductivity400℃(W/m.k) |
0.25 |
0.27 |
0.32 |
0.41 |
|
Thermal Expansion1000℃(%) |
0.5 |
0.7 |
0.8 |
0.9 |
B C serises
|
Item |
B-1 |
C-1 |
C-2 |
|
AL2O3(%) |
25-30 |
35-40 |
45-50 |
|
Fe2O3(%) |
2 |
1 |
1 |
|
Classification Temperature (℃) |
1000 |
1300 |
1400 |
|
Bulk Density (g/cm3) |
0.8-1 |
0.8-1 |
0.8-1 |
|
Cold Crushing Strength (Mpa) |
2-2.5 |
2.5-3.5 |
3.0-4.5 |
|
Thermal conductivity400℃(W/m.k) |
0.17 |
0.23 |
0.25 |
Competitive Advantage:
1.Best price, make the products competitive in your market
2.Abundant Experience.
3.Strict Quality Control. Meet clients'quality requirement.
4.Large stocks. Guarantee prompt delivery.
5.Professional Packing. Avoid damage and secure the goods in transportation
